Maxsun Challanger B650M-V2 AM5 DDR5 6000 Mhz M.2 HDMI mAtx AMD Anakart MS-CHL-B650M-V2

• CHIPSET

• AMD® B650 Chipset

• CPU (Max Support)

• Supports LGA1718 slot
  AMD RYZEN7000 Series
  TDP: 155W (6+2+1 items)

• MEMORY

• 2* DIMM DDR5 memory slots
  Supports dual-channel memory technology
  Support 4800MHZ/5200MHZ/OC Memeroy Frequency

• ONBOARD GRAPHICS

• 1x VGA
  *Support VGA, maximum resolution of 2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz
  1x HDMI™port
  *HDMI™ port supports up to 4K@30Hz
  *Graphics specifications may vary between CPU types.

• EXPANSION SLOT

• 1x PCIe 4.0 x16 slot
  1x PCIe 3.0 x4 slot
  1x PCIe 3.0 x1 slot

• STORAGE

• M.2 slot (Key M), type 2242/2280 (supports PCIe 4.0 x4 mode)
  4x SATA 6Gb/s ports

• USB

• Onboard rear ports: 4* USB3.2 GEN1 ports, 2* USB2.0 ports
  On-board pins: 1* set (2 pcs) of USB2.0 pins, 1* set (2 pcs) of USB3.2 GEN1 pins

• LAN

• Realtek® RTL8111HNIC Chip

• AUDIO

• Realtek® ALC897 Codec
  5.1-Channel High Definition Audio

• INTERNAL I/O

• 1x 24-pin Power Connector(ATX_PWR)
  1x 8-pin Power Connector(CPU_PWR)
  1x CPU Fan
  2x System Fan
  1x PS/2 interface
  1x M.2 slots (Key-M)
  4x SATA 6Gb/s ports
  1x 4-Pin SPEAKER
  1x Front Audio
  1x COM_A Port
  1x 9-Pin DEBUG_CON
  1x CLR CMOS

• SSD

• 1* M.2 4.0 slot (supports 2242/2280 PCIE X4/X2 channel SSD only)
  3* SATA3.0 ports

• OPERATING SYSTEM

• Support for Windows® 11 64-bit, Windows® 10 64-bit

• FORM FACTOR

• M-ATX
  245mm x 210mm
