Intel® Core™ i7, Core™ i5, Core™ i3processors, Socket LGA1156
Supports Intel® 45nm Hi-K CPU
Dual channel DDR3 1333/1066/800 x 2 DIMMs, Max. 8GB
1* PCIe2.0 x16, 1* PCIe x1, 2* PCI
6* SATA II
5.1 channel HDA
Gigabit LAN
12 USB 2.0 ports
Processor: Intel® Core™ i7,Core™ i5,Core™ i3 processors, Socket LGA1156
Chipset: Intel® H55
Front Side Bus:
Memory: Dual channel DDR3 1333/1066 x 2 DIMMs, Max. 8GB
VGA on Die: Integrated Intel® GMA HD graphics engine(need CPU support)
Expansion Slots: 1* PCIe2.0 x16, 1* PCIe x4,2* PCI
IDE: N/A
Serial ATA(SATA)/RAID: 6* SATAII
Audio: 5.1 channel HDA by Realtek® ALC662
LAN: Gigabit LAN by Realtek® 8111DL
IEEE1394: N/A
Back Panel I/O Ports: 1 x PS/2 keyboard port
1 x PS/2 Mouse port
1 x DVI connector
1 x VGA connector
1 x Audio jack supports 3 jacks
1 x RJ45 LAN port
6 x USB 2.0 ports
1 x Parallel port
Internal I/O Connectors: 1 x ATX 24-Pin power connector
1 x 4-pin ATX 12V power connector
2 x 4-pin CPU / System Fan connectors
1 x Front pannel header
1 x TPM header
1 x Speaker header
1 x Intruder Alarm header
3 x USB 2.0 connectors support additional 6 ports
6 x Serial ATAII connectors
1 x Front Audio Header
1 x S/PDIF Out header
1 x IrDA header
1 x COM header
BIOS Features: 64Mb flash EEPROM w/ LAN boot PnP, ACPI, WfM, DMI
Support CD: Drivers, Adobe Reader, SuperUtilities, Norton Internet Security
Standards/Manageability: PCI 2.3, USB2.0, DMI 2.5
Form Factor: Micro ATX (9.6" x 8.6")
