ATEN Stok Kodu : 404-369-123121 Barkod : 4719264647215
Distribütör garantili orijinal ATEN Kesintisiz Güç Kaynağı ürünleri için en uygun fiyat
Ürün Açıklaması
Yorumlar
Ödeme Seçenekleri
Geri Bildirim
Basic
Space saving -1U rack mount design
IEC or NEMA outlet models
Overcurrent Protection
Aluminum material
Typical Applications
Servers
Network Devices
Telecom Equipment
Function
PE0212A
PE0212B
PE0212G
Electrical
Nominal Input Voltage
100-120 VAC
100-240 VAC
100-240 VAC
Maximum Input Current
20A Max (UL de-rated 16A Max)
20A (Max) (UL de-rated 16A Max)
16A (Max)
Input Frequency
50-60 Hz
50-60 Hz
50-60 Hz
Input Connection
For A Plug NEMA L5-20P For A2 Plug : NEMA 5-20P
NEMA L6-20P
IEC-320 C20
Input Power
2400VA(MAX); 1920VA(UL de-rated)
4800VA(Max); 3840VA(UL de-rated)
3840VA(Max)
Outlet Type
(12) NEMA 5-20R
(12) IEC 320 C13
(12) IEC 320 C13
Maximum Output Current (Outlet)
20A (Max) (UL de-rated 16A Max)
15A (Max) (UL de-rated 12A Max)
10A (Max)
Maximum Output Current (Bank)
20A (Max) (UL de-rated 16A Max)
20A (Max) (UL de-rated 16A Max)
16A (Max)
Maximum Output Current (Total)
20A (Max) (UL de-rated 16A Max)
20A (Max) (UL de-rated 16A Max)
16A (Max)
OPD(Overcurrent Protection Device)
Yes
Yes
Yes
Physical Properties
Dimensions (L x W x H)
48.80 x 4.40 x 4.50 cm (19.21 x 1.73 x 1.77 in.)
48.80 x 4.40 x 4.50 cm (19.21 x 1.73 x 1.77 in.)
48.80 x 4.40 x 4.50 cm (19.21 x 1.73 x 1.77 in.)
Weight
0.88 kg ( 1.95 lb )
0.88 kg ( 1.95 lb )
0.88 kg ( 1.95 lb )
Power Cord Length
10ft(12#)
10ft(12#)
10ft(3×1.5mm2)
Environmental
Temperature (Operating / Storage)
0 – 40? / -20 – 60? *When the environmental temperature comes close 40 degrees, it is recommended to lower the load to 60% to comply to the safety regulations.
0 – 40? / -20 – 60? *When the environmental temperature comes close 40 degrees, it is recommended to lower the load to 60% to comply to the safety regulations.
0 – 40? / -20 – 60? *When the environmental temperature comes close 40 degrees, it is recommended to lower the load to 60% to comply to the safety regulations.
