Stok Kodu
: 404-369-123119
Detay Özellikler
- Space saving -1U rack mount design
- IEC or NEMA outlet models
- Surge Protection
- Over-current Protection
- Aluminum material
- Works with data centers, server rooms and telecom equipment
| Function |
PE0110SA |
PE0110SG |
| Electrical |
| Nominal Input Voltage |
100-120 VAC |
100-240 VAC |
| Maximum Input Current |
15A (Max)
(UL de-rated 12A Max)
(PSE 10A) |
10A (Max) |
| Input Frequency |
50-60 Hz |
50-60 Hz |
| Input Connection |
NEMA 5-15P |
For G Plug:IEC-320 C14
For Z Plug:Chinese 10A |
| Input Power |
1800VA(Max);1440VA(UL de-rated) |
2400VA(Max) |
| Outlet Type |
(10) NEMA 5-15R |
(10) IEC-320 C13 |
| Maximum Output Current (Outlet) |
15A (Max)
(UL de-rated 12A Max)
(PSE 10A) |
10A (Max) |
| Maximum Output Current (Bank) |
15A (Max)
(UL de-rated 12A Max)
(PSE 10A) |
10A (Max) |
| Maximum Output Current (Total) |
15A (Max)
(UL de-rated 12A Max)
(PSE 10A) |
10A (Max) |
| OPD(Overcurrent Protection Device) |
YES |
YES |
| Physical Properties |
| Dimensions (L x W x H) |
48.20 x 4.44 x 4.50 cm
(18.98 x 1.75 x 1.77 in.) |
48.20 x 4.44 x 4.50 cm
(18.98 x 1.75 x 1.77 in.) |
| Weight |
0.66 kg ( 1.45 lb ) |
0.66 kg ( 1.45 lb ) |
| Power Cord Length |
10ft(14#) |
10ft(3×1.5mm2) |
| Environmental |
| Temperature (Operating / Storage) |
0 – 40? / -20 – 60?
*When the environmental temperature comes close 40 degrees, it is recommended to lower the load to 60% to comply to the safety regulations. |
0 – 40? / -20 – 60?
*When the environmental temperature comes close 40 degrees, it is recommended to lower the load to 60% to comply to the safety regulations. |
| Elevation (Operating / Storage) |
3000m |
3000m |
| Compliance |
| EMC Verification |
FCC Class A |
- |
| Safety Verification |
By Request |
LVD |
| Note |
For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.
|
Package Contents
- 1x Basic PDU
- 1x Power cord
- 1x User Instructions
