Sapphire Radeon RX 6600 Pulse 8GB GDDR6 128 Bit Ekran Kartı 11310-01-20G

GPU

AMD Radeon™ RX 6600 Graphics Card
7nm GPU
AMD RDNA™ 2 Architecture

Engine Clock

• Boost Clock: Up to 2491 MHz
• Game Clock: Up to 2044 MHz

Boost Clock is the maximum frequency achievable on the GPU running bursty workload. Boost clock achievability, frequency, and sustainabilty will vary based on several factors, including but not limited to: thermal conditions and variation in application and workloads.

Game Clock is the expected GPU clock when running typical gaming applications, set to typical TGP(Total Graphics Power). Actual individual game clock results may vary.

Stream Processors

1792

Infinity Cache

32MB

Ray Accelerators

28

Memory Size/Bus

8GB GDDR6

Memory Clock

14 Gbps Effective

Displays

Maximum 4 Displays

Resolution

• HDMI™: 7680×4320
• DisplayPort1.4: 7680×4320

Interface

PCI-Express 4.0 x8

Output

• 1x HDMI
• 3x DisplayPort

BIOS Support

• UEFI

Game Index

1080P

Sapphire Features

• Premium Digital Power Design
• Fuse Protection
• Dual-X Cooling Technology
• Intelligent Fan Control
• Precision Fan Control
• Metal Backplate
• Two-Ball Bearing Fans
• TriXX Supported
• TriXX Boost

AMD Features

• AMD RDNA™ 2 Gaming Architecture
• DirectX® 12 Ultimate
• Hardware Raytracing
• Smart Access Memory
• Infinity Cache
• 7nm GPU
• PCI® Express 4.0 Support
• AMD FreeSync™ Technology
• DisplayPort™ 1.4 with DSC
• HDMI™
• Video Streaming up to 8K
• Radeon™ VR Ready Premium
• AMD FidelityFX
• Radeon™ Image Sharpening
• Radeon™ Anti-Lag
• Radeon™ Software
• Game Driver Optimizations

Cooler Type

Dual Fans

Form Factor

2 slot, ATX
Dimension: 193(L)X 120.05(W)X 40.05(H)mm

Power Consumption

• 140W (Board Power)

OS

Linux®, Windows® 7*, Windows® 10, and Windows 11 64-bit  operating system required

*Does not support all features including but not limited to Hardware Raytracing

System Requirement

• Minimum 500 Watt Power Supply
• 1 x 8-pin Power Connector.
• PCI Express® based PC is required with one X16 lane graphics slot available on the motherboard.
• Minimum 8GB of system memory. 16GB recommended.
