Teknik Özellikler
Veri Transfer Hızı
: 10/100/1000Mbps
Yönetilme Durumu
: Layer 2
Garanti Durumu
: Var, Başlamamış
Detay Özellikler
System Specifications
|
Description
|
I/O ports and slots
|
-
48 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 type 10BASE-T, IEEE 802.3u type 100BASE-TX, IEEE 802.3ab type 1000BASE-T)
-
Duplex: 10BASE-T/100BASE-TX: Half or full
-
1000BASE-T: Full only
-
4 fixed GbE SFP ports
|
Additional ports and slots
|
1 Dual-Personality (RJ-45 or USB Micro-B) serial console port
|
Memory and processor
|
-
ARM9E @ 800 MHz, 128MB flash
-
Packet buffer size: 3MB dynamically allocated, 256MB DDR3 DIMM
|
Mounting
|
|
Management
|
|
Performance (IPv6 Ready Certified)
|
Description
|
1000Mb latency
|
< 2.3 µs (LIFO 64-byte packets)
|
100Mb latency
|
< 7.4 µs (LIFO 64-byte packets)
|
Throughput
|
Up to 77.3 Mp/s (64-byte packets)
|
Switching capacity
|
104 Gb/s
|
MAC address table size
|
16000 entries
|
Physical Specifications
|
Description
|
Dimensions (H x W x D)
|
|
Weight
|
3.08 kg (6.8 lb)
|
Electrical Specifications
|
Description
|
Maximum heat dissipation
|
203 BTU/hr (214.17 kJ/hr)
|
Voltage
|
100 - 127 / 200 - 240 V ac
|
Current
|
1.2/0.7 A
|
Idle power1
|
29.5 W
|
Maximum power rating2
|
59.5 W
|
Frequency
|
50/60 Hz
|
NOTE:
- Idle power is the actual power consumption ofthe device with no ports connected
- Maximum power rating and maximum heat dissipation are the Worst-Case theoretical maximum numbers provided for planning the infrastructure with fully loaded PoE (If equipped), 100% traffic, all ports plugged in,and all modules populated
|
Environmental Specifications
|
Description
|
Operating temperature
|
0° to 45°C (32° to 113°F)
|
Operating relative humidity
|
15% to 95% @ 40°C (104°F), noncondensing
|
Non-Operating/storage temperature
|
(-40°) to 70°C ((-40°) to 158°F)
|
Non-Operating/storage relative humidity
|
15% to 90% @ 149°F (65°C), noncondensing
|
Altitude
|
Up to 3 km (10,000 ft)
|
Acoustic
|
Power: 31.0 dB, pressure: 34.5 dB
|
Safety Certifications
|
Description
|
Safety
|
-
UL 60950-1
-
CAN/CSA 22.2 No. 60950-1
-
EN 60825
-
IEC 60950-1
-
EN 60950-1
|
Emissions
|
|
Immunity
|
-
Generic: EN 55024, CISPR 24
-
EN: EN 55024, CISPR 24
-
ESD: IEC 61000-4-2
-
Radiated: IEC 61000-4-3
-
EFT/Burst IEC: 61000-4-4
-
Surge: IEC 61000-4-5
-
Conducted: IEC 61000-4-6
-
Power frequency magnetic field: IEC 61000-4-8
-
Voltage dips and interruptions: IEC 61000-4-11
-
Harmonics: EN 61000-3-2, IEC 61000-3-2
-
Flicker: EN 61000-3-3, IEC 61000-3-3
|
NOTE:
- IEEE 802.3az applies to Gb models only
- IEEE 802.3at and IEEE 802.3af apply to PoE+ models only
- When using SFPs with this product, SFPs with revision B or later (Product number ends with the letter B or later, e.g., J4858B, J4859C) are required
|
