Arayüz
|
| Fixed WAN Port |
1x RJ-11 for VDSL2 or ADSL2/2+ |
| LAN/WAN Switchable Port |
1x 10/100/1000Base-TX RJ-45 |
| Fixed LAN Port |
5x 10/100/1000Base-TX RJ-45 |
| USB Port |
2x USB 2.0 |
| 2.4G WLAN |
802.11n 2x2 MIMO 400Mbps (ac model) |
| 5G WLAN |
802.11ac wave 2 2x2 MIMO 867Mbps (ac model) |
Performans
|
| NAT Throughput |
800 Mbps |
| IPsec VPN Performance |
300 Mbps (AES 256 bits) |
| SSL VPN Performance |
120 Mbps |
| Max. Number of NAT Sessions |
60,000 |
| Max. Concurrent VPN Tunnels |
32 |
| Max. Concurrent OpenVPN + SSL VPN |
16 |
VDSL/ADSL
|
| VDSL Standards |
G.993.2 (VDSL2), G.993.5 (vectoring) |
| VDSL2 Profile |
8a, 8b, 8c, 8d, 12a, 12b, 17a, 35b (not G.Fast) |
| ADSL Standards |
ANSI T1.413, ITU-T G.992.1(G.dmt) |
| ADSL2 Standards |
ITU-T G.992.3 Annex A/L/M |
| ADSL2+ Standards |
ITU-T G.992.5 Annex A/M |
Internet Bağlantısı
|
| IPv4 |
PPPoE, DHCP, Static IP, PPTP/L2TP |
| IPv6 |
PPP, DHCPv6, Static IPv6, TSPC, AICCU, 6rd, 6in4 Static Tunnel |
| 802.1p/q Multi-VLAN Tagging |
V |
| Multi-VLAN/PVC |
V |
| 3G/4G/LTE WAN with USB modem |
V |
| Load Balancing |
IP-based, Session-based |
| WAN Active on Demand |
Link Failure, Traffic Threshold |
| Connection Detection |
ARP, Ping |
| WAN Data Budget |
V |
| Dynamic DNS |
V |
| DrayDDNS |
V |
LAN Yönetimi
|
| VLAN |
802.1q Tag-based, Port-based |
| Max. Number of VLAN |
16 |
| Number of LAN Subnet |
8 |
| DHCP Server |
Multiple IP Subnet, Custom DHCP Options, Bind-IP-to-MAC |
| LAN IP Alias |
V |
| Wired 802.1x Authentication |
V |
| Port Mirroring |
V |
| Local DNS Server |
V |
| Conditional DNS Forwarding |
V |
| Hotspot Web Portal |
V |
| Hotspot Authentication |
Click-Through, Social Login, SMS PIN, Voucher PIN, RADIUS, External Portal Server |
Ağ
|
| Routing |
IPv4 Static Routing, IPv6 Static Routing, Inter-VLAN Routing, RIP, BGP |
| Policy-based Routing |
Protocol, IP Address, Port, Domain, Country |
| High Availability |
V |
| DNS Security (DNSSEC) |
V |
| Multicast |
IGMP Proxy, IGMP Snooping & Fast Leave, Bonjour |
| Local RADIUS server |
V |
| SMB File Sharing |
V (Requires external storage) |
VPN
|
| LAN-to-LAN |
V |
| Teleworker-to-LAN |
V |
| Protocols |
PPTP, L2TP, IPsec, L2TP over IPsec, SSL, GRE, IKEv2, IKEv2-EAP, IPsec-XAuth, OpenVPN |
| User Authentication |
Local, RADIUS, LDAP, TACACS+, mOTP |
| IKE Authentication |
Pre-Shared Key, X.509 |
| IPsec Authentication |
SHA-1, SHA-256 |
| Encryption |
MPPE, DES, 3DES, AES |
| VPN Trunk (Redundancy) |
Load Balancing, Failover |
| Single-Armed VPN |
V |
| NAT-Traversal (NAT-T) |
V |
Güvenlik Duvarı ve İçerik Filtreleme
|
| NAT |
Port Redirection, Open Ports, Port Triggering, DMZ Host, UPnP |
| ALG (Application Layer Gateway) |
SIP, RTSP, FTP, H.323 |
| VPN Pass-Through |
PPTP, L2TP, IPsec |
| IP-based Firewall Policy |
V |
| Content Filtering |
Application, URL, DNS Keyword, Web Features, Web Category* (*: subscription required) |
| DoS Attack Defense |
V |
| Spoofing Defense |
V |
Bantgenişliği Yönetimi
|
| IP-based Bandwidth Limit |
V |
| IP-based Session Limit |
V |
| QoS (Quality of Service) |
TOS, DSCP, 802.1p, IP Address, Port, Application |
| VoIP Prioritization |
V |
Kablosuz LAN (ac model)
|
| Number of SSID |
4 per radio band |
| Security Mode |
WEP, WPA, WPA2, Mixed(WPA+WPA2) |
| Authentication |
Pre-Shared Key, 802.1X |
| WPS |
PIN, PBC |
| WDS |
Bridge, Repeater (5G Only) |
| Access Control |
Access List, Client Isolation, Hide SSID, Wi-Fi Scheduling |
| AirTime Fairness |
V |
| Band Steering |
V |
| MU-MIMO |
V |
| Beamforming |
V |
| WMM |
V |
Yönetim
|
| Local Service |
HTTP, HTTPS, Telnet, SSH, FTP, TR-069 |
| Config File Export & Import |
V |
| Firmware Upgrade |
TFTP, HTTP, TR-069 |
| 2-Level Administration Privilege |
V |
| Access Control |
Access List, Brute Force Protection |
| Notification Alert |
SMS, E-mail |
| SNMP |
v1, v2c, v3 |
| Syslog |
V |
| Managed by VigorACS |
V |
| Central VPN Management |
8 VPN |
| Central AP Management |
20 VigorAP |
| Central Switch Management |
10 VigorSwitch |
Fiziksel
|
| Power Supply |
DC 12V @ 4A-4.5A |
| Max. Power Consumption |
24 watts (ac model) |
| Dimension |
241mm x 166mm x 46mm |
| Weight |
620g (ac model) |
| Operating Temperature |
0 to 45°C |
| Storage Temperature |
-25 to 70°C |
| Operating Humidity (non-condensing) |
10 to 90% |
| Certificate |
 |
