Size
• 19-inch Desktop/Rackmount size, 1U height
Device Interfaces
• 8 10/100/1000 Mbps ports
Port Standards & Functions
• IEEE 802.3i 10BASE-T
• IEEE 802.3u 100BASE-TX
• IEEE 802.3ab 1000BASE-T Gigabit Ethernet
• IEEE 802.3at Power over Ethernet
• IEEE 802.3az Energy Efficient Ethernet
• IEEE 802.3x Flow Control supports half/full duplex mode
• ANSI/IEEE 802.3 NWay auto-negotiation
Switching Capacity
• 16 Gbps switching fabric
Media Interface Exchange
• Auto MDI/MDIX
Transmission Method
• Store-and-forward
MAC Address Table
• 8K entries per device
Packet Buffer Memory
• 128 KB per device
Packet Filtering/Forwarding Rates
• Ethernet: 14 880 pps per port
• Fast Ethernet: 148 800 pps per port
• Gigabit Ethernet: 1 488 800 pps per port
Data Transfer Rates
• Ethernet:
• 10 Mbps (half duplex)
• 20 Mbps (full duplex)
• Fast Ethernet:
• 100 Mbps (half duplex)
• 200 Mbps (full duplex)
• Gigabit Ethernet:
• 2000 Mbps (full duplex)
Network Cables
• 10BASE-T:
UTP CAT 3/4/5/5e (100 m max.)
EIA/TIA-586 100-ohm STP (100 m max.)
• 100BASE-TX:
UTP CAT 5/5e (100 m max.)
EIA/TIA-568 100-ohm STP (100 m max.)
• 1000BASE-T:
UTP CAT 5/5e(100 m max.)
EIA/TIA-568 100-ohm STP(100 m max.)
Physical Parameters
LED Indicators
• Per port: Activity / Link and Speed
• Per port: Power / Status
• PoE Max 1: Ports 1-4
• PoE Max 2: Ports 5-8
Dimensions
• 280 x 180 x 44 mm
Weight
• 1.8274 kg
Power Input
• AC Input: 100 to 240 V AC, 50/60 Hz
Maximum PoE Budget
• 140 watts
MTBF (hours)
• 326 125
Power Consumption
• 13.5 watts (PoE off)
• 151 watts (PoE on)
• PoE up to 30 watts per port
Temperature
• Operating: 0?° to 40?°C
• Storage: -10?° to 70?°C
Humidity
• Operating: 0% to 95% (Non-condensing)
• Storage: 5% to 95% (Non-condensing)
EMI
• CE Class A
• FCC Class A
• VCCI Class A
• CCC Class A
• BSMI Class A
Safety
• cUL
• CB
• LVD
• CCC
• BSMI
