| Hardware Specifications | |
| 10/100/1000 Mbps RJ-45 ports | 3 x LAN, 1 x OPT, 1 x WAN |
| USB ports | 2 x USB 2.0 |
| Fanless | Yes |
| System Capacity & Performance*1 | |
| SPI firewall throughput (Mbps)*2 | 1.5Gbps |
| VPN throughput (Mbps)*3 | 35 |
| Max. TCP concurrent sessions*4 | 50,000 |
| Max. concurrent IPsec VPN tunnels *5 | 20 |
| Customizable zones | Yes |
| IPv6 support | Yes |
| VLANs | 16 |
| Key Software Features | |
| Multi-WAN Load Balance/Failover | Yes |
| Virtual private network (VPN) | Yes (IPSec, L2TP over IPSec, PPTP, L2TP, GRE) |
| VPN Client | IPSec/L2TP/PPTP |
| Content filtering | 1 year free |
| Firewall | Yes |
| VLAN/Interface Group | Yes |
| Bandwidth management | Yes |
| Logging and monitoring | Yes |
| Cloud Helper | Yes |
| Remote Management | Yes |
| Power Requirements | |
| Power input | 110 to 240V AC, 50/60 Hz, 1.5A max. |
| Max. power consumption (watt) | 13.1 |
| Heat dissipation (BTU/hr) | 44.7 |
| Physical Specifications | |
| Item dimensions (WxDxH) (mm/in.) | 210 x 115 x 33/8.27 x 6.06 x 1.57 |
| Item weight (kg/lb.) | 0.495/1.09 |
| Packing dimensions (WxDxH) (mm/in.) | 288 x 189 x 83/11.34 x 7.44 x 3.27 |
| Packing weight (kg/lb.) | 1.13/2.49 |
| Included accessories | Power adapter |
| Environmental Specifications | |
| Operating Temperature | 0°C to 40°C/32°F to 104°F |
| Operating Humidity | 20% to 95% (non-condensing) |
| Storage Temperature | -30°C to 60°C/-22°F to 140°F |
| Storage Humidity | 20% to 95% (non-condensing) |
| MTBF (hr) | 44,000 |
| Certifications | |
| EMC | FCC Part 15B (Class B), FCC Part 68 , CE EMC (Class B) |
| Safety | CE LVD |
|
Models
|
|
|---|---|
| Hardware Specifications | |
| 10/100/1000 Mbps RJ-45 ports | |
| USB ports | |
| Fanless | |
| System Capacity & Performance*1 | |
| SPI firewall throughput (Mbps)*2 | |
| VPN throughput (Mbps)*3 | |
| Max. TCP concurrent sessions*4 | |
| Max. concurrent IPsec VPN tunnels *5 | |
| Customizable zones | |
| IPv6 support | |
| VLANs | |
| Key Software Features | |
| Multi-WAN Load Balance/Failover | |
| Virtual private network (VPN) | |
| VPN Client | |
| Content filtering | |
| Firewall | |
| VLAN/Interface Group | |
| Bandwidth management | |
| Logging and monitoring | |
| Cloud Helper | |
| Remote Management | |
| Power Requirements | |
| Power input | |
| Max. power consumption (watt) | |
| Heat dissipation (BTU/hr) | |
| Physical Specifications | |
| Item dimensions (WxDxH) (mm/in.) | |
| Item weight (kg/lb.) | |
| Packing dimensions (WxDxH) (mm/in.) | |
| Packing weight (kg/lb.) | |
| Included accessories | |
| Environmental Specifications | |
| Operating Temperature | |
| Operating Humidity | |
| Storage Temperature | |
| Storage Humidity | |
| MTBF (hr) | |
| Certifications | |
| EMC | |
| Safety | |
Note: This matrix with firmware OPAL BE 1.12 or later.
*1: Actual performance may vary depending on network conditions and activated applications.
*2: Maximum throughput measured based on RFC 2544 (1,518-byte UDP packets).
*3: VPN throughput based on RFC 2544 (1,424-byte UDP packets).
*4: Maximum sessions measured using the industry standard IXIA IxLoad testing tool.
*5: Including Gateway-to-Gateway and Client-to-Gateway.
