Brand: SONICWALL
Series: TZ 105
Model: 01-SSC-4906
Firewall Type: Gen 3 Application-Layer
Type: Wired
Standard: TCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3
Wireless Technology: None
Throughput: 200 Mbps
Ports: 5 x 10/100 Fast Ethernet, 1 x USB, 1 x Console
LAN Ports: 5 x RJ-45
WAN Ports: Configurable
Wired Speed: 10/100 Mbps
LEDs: Power, Test, Link/Activity
Security:
- Deep Packet Inspection Services: Gateway Anti-Virus, Anti-Spyware, Intrusion Prevention
- Content Filtering Service (CFS): HTTP URL, HTTPS IP, keyword and content scanning, -ActiveX, Java Applet, and cookie blocking bandwidth management on filtering categories, allow/forbid lists
- Enforced Client Anti-Virus and Anti-Spyware: McAfee or Kaspersky
- Comprehensive Anti-Spam Service: Supported
- Application Intelligence and Control: Application Control
Encryption Standard: DES, 3DES, AES (128, 142, 256-bit), MD5, SHA-1/DH Group 1, 2, 5, 14
VPN:
- 3DES/AES Throughput: 75 Mbps
- Site-to-Site VPN Tunnels: 5
- Bundled GVC Licenses (Maximum): 0 (5)
- Bundled SSL VPN Licenses (Maximum): 1 (5)
- Key Exchange: IKE, Manual Key, Certificates (X.509), L2TP over IPSec
- Certificate Support: Verisign, Thawte, Cybertrust, RSA Keon, Entrust and Microsoft CA for SonicWALL-to-SonicWALL VPN, SCEP
- VPN Features: Dead Peer Detection, DHCP Over VPN, IPSec NAT Traversal, Redundant VPN Gateway, Route-based VPN
- Global VPN Client: Platforms Supported Microsoft Windows XP, Vista 32/64-bit, Windows 7 32/64-bit
- SSL VPN Platforms: Microsoft Windows XP/Vista 32/64-bit/Windows 7, Mac OSX 10.4+, Linux FC3+/Ubuntu 7+/OpenSUSE
- Mobile Connect Platform Supported: Apple iOS 4.2 or higher, Google Android 4.0 or higher.
Power Input: 100 to 240 VAC, 50-60 Hz, 1 A
Dimensions: 5.555" x 1.42" x 7.48"
Weight: 0.75 lbs.
Features:
- Firewall:
- SonicOS Version: SonicOS 5.8.1 and later
- Stateful Throughput: 200 Mbps
- IPS Throughput: 60 Mbps
- GAV Throughput: 40 Mbps
- UTM Throughput: 25 Mbps
- Maximum Connections: 8000
- Maximum UTM/DPI Connections: 8000
- New Connections/Sec: 1000
- Denial of Service Attack Protection: 22 classes of DoS, DDoS and scanning attacks
- SonicPoints Supported: 1
- Networking:
- -IP Address Assignment: Static, (DHCP, PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP relay
- -NAT Modes: 1:1, 1:many, many:1, many:many, flexible NAT (overlapping IPs), PAT, transparent mode
- -VLANS: 5, PortShield
- -DHCP: Internal server, relay
- -Routing: OSPF, RIP v1/v2, static routes, policy-based routing, multicast
- -Authentication: XAUTH/RADIUS, Active Directory, SSO, LDAP, Novell, internal user database, Terminal Services, Citrix
- -Local User Database: 150 users
- -VoIP Full H.323v1-5, SIP, gatekeeper support, outbound bandwidth management, VoIP over WLAN, deep inspection security, full interoperability with most VoIP gateway and communications devices.
- System:
- -Zone Security: Yes
- -Schedules: Yes
- -Object-based/Group-based Management: Yes
- -DDNS: Dynamic DNS providers include: dyndns.org, yi.org, no-ip.com and changeip.com
- -Management and Monitoring: Local CLI, Web GUI (HTTP, HTTPS), SNMP v2; Global management with SonicWALL GMS
- -Logging and Reporting: Analyzer, Scrutinizer, GMS, Local Log, Syslog, Solera Networks
- -Anti-Spam
- -Load Balancing
- -WAN Acceleration Support
- Processor: Single-Core
- Flash Memory/RAM: 32 MB/256 MB
