Image Sensor

1/2.8” 1.3Megapixel progressive scan Hisilicon CMOS

Effective Pixels

1.3M(1280x1024)

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual, 1/3~1/10000s

Min. Illumination

0. 01Lux/F1.2 (Color), 0.005Lux/F1.2(B/W);0Lux/F1.2(IR on)

S/N Ratio

More than 50dB

Video Output

N/A

Camera Features

Max. IR LEDs Length

30m

Day/Night

Auto(ICR)/Color/B/W

Backlight Compensation

BLC / HLC / DWDR

White Balance

Auto/Manual

Gain Control

Auto/Manual

Noise Reduction

2D

Privacy Masking

Up to 4 areas

Lens

Focal Length

3.6mm

Max Aperture

F1.6

Focus Control

Manual

Angle of View

H: 70°(114°/46°)

Lens Type

Fixed lens

Mount Type

Board-in Type

Video

Compression

H.264 (BL/MP/HP)

Resolution

1.3M(1280x1024)/720P(1280×720)/VGA(640×480)/QVGA(320×240)

Frame Rate

Main Stream

Sub Stream

VGA/QVGA(1 ~ 30fps)

Bit Rate

Audio

Compression

N/A

Interface

N/A

Network

System Framework

528 MHz ARM1136J-S Ambaralla A5S

Ethernet

RJ-45 (10/100Base-T)

Wi-Fi

N/A

Protocol

IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour,

ONVIF

ONVIF Version 2

Max. User Access

20 users

Smart Phone

iPhone, iPad, Android, Windows Phone

Auxiliary Interface

Memory Slot

N/A

RS485

N/A

Alarm

N/A

PIR Sensor Range

N/A

General

Power Supply

DC12V

Power Consumption

Working Environment

-20°C~+60°C, Less than 95% RH

Ingress Protection

IP66

Vandal Resistance

N/A
