Function |
VE1821R |
VE1821T |
|
Video Input |
|
Interfaces |
N/A |
1 x HDMI Type A Female (Black) |
|
Impedance |
N/A |
100 ? |
|
Max. Distance |
N/A |
3 m |
|
Video Output |
|
Interfaces |
1 x HDMI Type A Female (Black) |
1 x HDMI Type A Female (Black) |
|
Impedance |
100 ? |
100 ? |
|
Max. Distance |
3 m |
3 m |
|
Video |
|
Max. Data Rate |
10.2Gbps (3.4Gbps per lane) |
10.2Gbps (3.4Gbps per lane) |
|
Max. Pixel Clock |
340 MHz |
340 MHz |
|
Compliance |
HDMI (3D, Deep Color, 4K)
HDCP1.4 Compatible |
HDMI (3D, Deep Color, 4K)
HDCP1.4 Compatible |
|
Max. Resolutions / Distance |
Up to 4K@30m (Cat5e), 40m (Cat 6/ATEN 2L-2910);
*4K supported:
4096 x 2160 / 3840 x 2160 @ 30Hz (4:4:4) |
Up to 4K@30m (Cat5e), 40m (Cat 6/ATEN 2L-2910);
*4K supported:
4096 x 2160 / 3840 x 2160 @ 30Hz (4:4:4) |
|
Audio |
|
Input |
N/A |
1 x HDMI Type A Female (Black) |
|
Output |
1 x HDMI Type A Female (Black) |
N/A |
|
Control |
|
IR Channel |
1 x Mini Stereo Jack Female (Black);
Single way bypass channel from receiver to transmitter |
1 x Mini Stereo Jack Female (Black);
Single way bypass channel from receiver to transmitter |
|
Switches |
|
Mode Switch |
N/A |
EDID Mode Selection (Read EDID from Transmitter HDMI output or Receiver HDMI output) |
|
Connectors |
|
Power |
1 x RJ-45 Female
(Power over Cable, power supply from VE1821T) |
1 x DC Jack (Black) with locking |
|
Unit To Unit |
1 x RJ-45 Female |
1 x RJ-45 Female |
|
Power Consumption |
POC:0.87W:4BTU |
DC12V:1.86W:9BTU |
|
Environmental |
|
Operating Temperature |
0 - 40°C |
0 - 40°C |
|
Storage Temperature |
-20 - 60°C |
-20 - 60°C |
|
Humidity |
20 - 90% RH, Non-Condensing |
20 - 90% RH, Non-Condensing |
|
Physical Properties |
|
Housing |
Metal |
Metal |
|
Weight |
0.12 kg ( 0.28 lb ) |
0.12 kg ( 0.28 lb ) |
|
Dimensions (L x W x H) with bracket |
7.95 x 6.80 x 1.65 cm
(3.13 x 2.68 x 0.65 in.) |
7.95 x 6.80 x 1.65 cm
(3.13 x 2.68 x 0.65 in.) |
|
Dimensions (L x W x H) without bracket |
5.75 x 6.80 x 1.65 cm (2.26 x 2.68 x 0.65 in.) |
5.75 x 6.80 x 1.65 cm (2.26 x 2.68 x 0.65 in.) |
